In FLUID200 the internal tank is heated with two electricalresistances and cooled by a fan.
FLUID200 is equipped with a new PID microprocessor controllerwith a resolution up to 0,01 °C, setting of the standard ofmeasurement in °C, °F and K, programming of ascent/descentramps and storage of the thermostats operative temperature. Themixing process ensures a proper heat transmission, excellentstability and uniformity values; the large size of the well makesit possible to test sensors of various lengths and diameters.
In the FLUID200-2I version, the instrument is equipped with anacquisition card having two adjustable inputs (Pt100 3/4 wires,thermocouples: E, J, K, N, R, S) with bushes fitted withgold-plated contacts and automatic compensation of the coldjunction.
The REF input is provided for the reference sample probe, thusobtaining a complete calibration system which can be certified byAccredia centres, in compliance with ISO 9000 regulations.
The EXT input is provided for probes that are being tested;hence, the instrument can display the temperature of the well, thetemperature of the sensor to be checked and the temperature of thereference sample probe, at the same time.
Furthermore, FLUID200 is equipped with the RS232 serialinterface; it can operate in automatic mode connected to the PC bymeans of the AQ2sp software which enables to carry out probecalibrations, thermostats tests, and cyclical life tests; testresults can be stored and printed, so they are easily traceable incompliance with ISO 9000 standards.
Technical specification FLUID 200
Operating range Room temp. ÷ +200 °C
Room temp. ÷ +392 °F
Average heating time
(stabilization included) 10 °C/min (50 °F/min)
Average cooling time
(stabilization included) 4 °C/min (39 °F/min)
Axial uniformity ±0,05°C / ±0.09°F at 0°C / 32°F (for 60 mm from the bottom)
Radial uniformity (at 40 mm) ±0,05 °C
(at 50 mm) ±0.09 °F (at 50 mm)
Hole depth 170 mm (6.6 in.)
Hole diameter 60mm (2.3 in.)
Display accuracy ±0,15 °C (±0.27 °F)
Stability ±0,02 °C at -5°C (±0.03 °F at 23 °F)
All temperatures 0,1 °C / 0,01 °F
Units of measure °C - °F - K
Switch test yes
Calibrator size 160 x 340 x 330 mm (6,2x13,3x12,9 in.)
Calibrator weight 8 kg (17 lb)
Power supply 115 or 230 VAC - 50/60 Hz
Electric power 500 W
